Penberthy GH = HG

Model HG 1/2" BRZ

1/2" Model HG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft...

Model HG 3/4" BRZ

3/4" Model HG in Bronze Motive Connection: 1/2" MNPTSuction Connection: 3/4" MNPTDischarge Connection: 3/4" MNPT Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.

Model HG 1" BRZ

1" Model HG in Bronze Motive Connection (Nozzle): 3/4" MNPT Suction Connection: 1" MNPT Discharge Connection: 1" MNPT Performance: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft...

Model HG 1-1/4" BRZ

1-1/4" Model HG in Bronze Motive Connection (nozzle): 1" MNPT Suction Connection: 1-1/4" MNPT Discharge Connection: 1-1/4" MNPT Performance: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift:...

HG 1-1/2" BRZ

1-1/2" Model HG in Bronze Motive Connection: 1-1/4" MNPTSuction Connection: 1-1/2" MNPTDischarge Connection: 1-1/2" MNPT Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required...

Model HG 2" BRZ

2" Model HL in Bronze Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.

Model HG 2-1/2" BRZ

2-1/2" Model HG in Bronze Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.

Model HG 3" BRZ

3" Model HG in Bronze Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.
