Penberthy GL = SG

Model SG 1/2" BRZ

1/2" Model SG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction...

Model SG 1/2" BRZ for refrigerant use

1/2" Model SG in Bronze fitted with neoprene o-ring Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

Model SG 3/4" BRZ

3/4" Model SG in Bronze Motive Connection: 1/2" mnpt Suction Connection: 3/4" mnpt Discharge Connection: 3/4" mnpt Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft...

Model SG 3/4" BRZ for refrigerant use

3/4" Model SG in Bronze fitted with neoprene o-ring Motive Connection: 1/2" mnpt Suction Connection: 3/4" mnpt Discharge Connection: 3/4" mnpt  Performance: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

Model SG 1" BRZ

1" Model SG in Bronze Motive Connection: 3/4" MNPTSuction Connection: 1" MNPTDischarge Connection: 1" MNPT Performance: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction...

Model SG 1-1/4" BRZ

1-1/4" Model SG in Bronze Motive Connection (nozzle): 1" MNPT Suction Connection: 1-1/4" MNPT Discharge Connection: 1-1/4" MNPT Performance: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum...

Model SG 1-1/2" BRZ

1-1/2" Model SG in Bronze Motive Connection: 1" MNPTSuction Connection: 1-1/2" MNPTDischarge Connection: 1-1/2" MNPT Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft...

Model SG 2" BRZ

2" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.

Model SG 2-1/2" BRZ

2-1/2" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.

Model SG 3" BRZ

3" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft.
