Replace Penberthy

NCI jet pumps and eductors match Penberthy jet pumps and eductors in connection sizes, performance & dimensions.  There is no need for re-piping or re-sizing.  The product is supported by a knowledgeable staff, large inventory and backed by World Class Manufacturing.

While our competition design their eductors for nominal pressure ratings, we offer eductors designed and produced to meet rigorous ASME/ANSI specifications.  Offer ratings are about 30% higher than most competitors.  300# ANSI rated provide material ratings as follows: 316SS: 720 psig @ 100 F | Carbon Steel: 740 psig @ 100 F | Bronze: 500 psig @ 100 F

Need Help ?  Give us a call: 201-419-6111  Extension 23 for our Jet Pump & Eductor Group.

PENBERTHY CROSS OVER TABLE

Penberthy Model Replace with Model Material of Construction
Penberthy Model LL Model SL Carbon Steel Bronze 316SS
Penberthy Model LM Model ML Carbon Steel Bronze 316SS
Penberthy Model LH Model HL Carbon Steel Bronze 316SS
Penberthy Model GL Model SG Carbon Steel Bronze 316SS
Penberthy Model GH Model HG Carbon Steel Bronze 316SS
Penberthy Model HLM Model MLH Carbon Steel Bronze 316SS
Penberthy Model ELL Model MLE Carbon Steel Bronze 316SS
Penberthy Model RJ Model ULJ Carbon Steel Bronze 316SS
Penberthy Model CTE Model TLM Carbon Steel 316SS

Penberthy Model TME Model TLM Polypropylene PVDF



Select a material of construction to narrow your search:

  • Model HL 2-1/2" BRZ Model HL 2-1/2" BRZ

    Model HL 2-1/2" BRZ

    2-1/2" Model HL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.
    $1,741.00
    Add to Cart
  • Model HL 2-1/2" CS Model HL 2-1/2" CS

    Model HL 2-1/2" CS

    2-1/2" Model HL in Carbon Steel Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction.   Motive Connection: 2" MNPT Suction...
    $999.90
    Choose Options
  • Model HL 3" 316SS

    Model HL 3" 316SS

    3" Model HL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.
    $4,123.80
    Add to Cart
  • Model HL 3" BRZ Model HL 3" BRZ

    Model HL 3" BRZ

    3" Model HL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.
    $2,369.00
    Add to Cart
  • Model HL 3" CS Model HL 3" CS

    Model HL 3" CS

    3" Model HL in Carbon Steel Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction. Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...
    $1,445.40
    Choose Options
  • Model HL 3/4" 316SS Model HL 3/4" 316SS

    Model HL 3/4" 316SS

    3/4" Model HL in 316SS Motive Connection: 1/2" MNPTSuction Connection: 3/4" MNPTDischarge Connection: 3/4" MNPT Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH:...
    $649.80
    Add to Cart
  • Model HL 3/4" BRZ Model HL 3/4" BRZ

    Model HL 3/4" BRZ

    3/4" Model HL in Bronze Motive Connection: 1/2" MNPTSuction Connection: 3/4" MNPTDischarge Connection: 3/4" MNPT Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.
    $426.70
    Add to Cart
  • Model HL 3/4" CS Model HL 3/4" CS

    Model HL 3/4" CS

    3/4" Model HL in Carbon Steel Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction. Motive Connection: 1/2" MNPTSuction Connection: 3/4"...
    $268.00
    Choose Options
  • Model ML 1" 316SS Model ML 1" 316SS

    Model ML 1" 316SS

    1" Model ML in 316SS Motive Connection (nozzle): 3/4" MNPT Suction Connection:  1" MNPT Discharge Connection: 1" MNPT Performance: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift:...
    $750.60
    Add to Cart
  • Model ML 1" BRZ Model ML 1" BRZ

    Model ML 1" BRZ

    1" Model ML in Bronze Motive Connection: 3/4" MNPTSuction Connection: 1" MNPTDischarge Connection: 1" MNPT Performance: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum...
    $516.80
    Add to Cart
  • Model ML 1" CS Model ML 1" CS

    Model ML 1" CS

    1" Model ML in Carbon Steel Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction. Motive Connection: 3/4" MNPTSuction Connection:...
    $344.00
    Choose Options
  • Model ML 1-1/2" 316SS Model ML 1-1/2" 316SS

    Model ML 1-1/2" 316SS

    1-1/2" Model ML in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft.
    $1,095.30
    Add to Cart
